Weiand 7540 - Stealth Ram™ Intake Manifold

Weiand 7540 - Stealth Ram™ Intake Manifold

Intake Manifold - Stealth Ram - Throttle Body Flange - Multi Port - Aluminum - Natural - Small Block Chevy - Each

Stealth Ram™ Intake Manifold; Lower; Power Band Idle-6500 RPM; High Rise; D-Shaped Runners; Universal Mount Bolt Design; 10.25in. Frt/Rear Height; No EGR Provision; Satin Finish;

The Weiand Stealth Ram(TM) intake is a revolutionary, radical departure from the ordinary. Designed to take advantage of the benefits associated with high ram manifolds, it combines aggressive race inspired looks with the drivability of EFI. Designed primarily as a component of the Holley Stealth Ram(TM)/Commander 950 EFI system, the manifold is now available for retrofit on L-98 TPI engines and other street/strip machines utilizing standard or 1987 and later aluminum Chevy cylinder heads. The manifold is designed to accept OEM and aftermarket TPI throttle bodies and includes provisions for mounting bracketry necessary for kickdown, cruise and throttle cables. Whether you are looking for more power for that late 80's Camaro or a new look for your street machine, look to Weiand. *** Use Holley 2x58mm billet throttle body (p/n 112-503 or 112-507) or stock TPI throttle body. Requires use of small cap distributor. Manifold features universal mounting bolt design engineered to accommodate both straight and angled center manifold bolts (requires P/N 90748 Weiand bolt kit for 1987 & later cast iron). Accepts stock or Lokar(R) TPI kickdown brackets. May require additional sealing modifications for high boost blow through applications. Will not fit Corvette due to manifold height

• Idle-6500 RPM Power Band
• D Shaped Runners Promote High Flow Rates w/o Turbulence
• No EGR Provisions
• 2-Piece Design Has Short Individual Runners/Large Upper Plenum
• Precision CNC Machining
• Permanent Mold Casting
• Satin Finish
