Weiand 7516 - X-CELerator Intake Manifold

Weiand 7516 - X-CELerator Intake Manifold

Intake Manifold - X-Celerator - Square Bore - Single Plane - Aluminum - Natural - 2V Head - Ford Cleveland / Modified - Each

X-CELerator Intake Manifold; Upper; Power Band 1500-7000 RPM; Low Rise; w/2V Heads; Square Carb Mounting Flange; 4.28 in. Front H/5.36 in. Rear Height; Satin Finish;

The WEIAND X-CELerator SERIES: 360°, single-plane, open plenum manifold designed primarily for high-performance street, drag, marine and oval track use. With an effective rpm range of 2000 to 6500 rpm, this series works best with ahigher compression ratio, 280° or more of cam duration and headers with 1-5/8 primary tubes. Being a mid- to high-rpm manifold, a standard transmission, or an automatic transmission with a 3000 rpm stall converter, is highly recommended. The carburetor mounting pad is designed to accept current performance aftermarket carburetors. The WEIAND X-CELerator Series is the ultimate street/strip performance manifold for single 4Vapplications where increased torque and power is required in the mid and high rpm ranges.

• Single Plane Design
• Square Carburetor Mounting Flange
• Power band: 1500-7000 RPM
• Height: Front 4.28", Rear 5.36"
• Port Size: 1.95” height 1.34" width
• No EGR provision
• New updated casting design
