Superwinch S100430 - Industrial SI 12000 Hydraulic Winch

Superwinch  |  SKU: SWINCH-S100430
$000


AVAILABILITY: This Item Is No Longer Orderable. Contact Us For More Details.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Superwinch S100430 - Industrial SI 12000 Hydraulic Winch

SI 12000 Hydraulic Winch

Hydraulic Winch; 12000 lbs.; Standard Drum; Manual Free-Spool; 2-Stage Planetary; 16:1 Gear Ratio; Spring Applied Hydraulic Release Multi Disc Brake; Roller Fairlead;

Superwinch designs and delivers automotive products that give you the function you need to fit your active lifestyle. Superwinch products are proudly designed, tested and engineered in San Dimas, California, USA. Innovation, passion and consistency have made Superwinch one of the industry's leading manufacturers. Our diverse range of products is backed by a superior manufacturer warranty. When it comes to your vehicle, Superwinch is the name you can trust.

  • 12000 lb. standard drum hydraulic winch
  • 16:1 gear ratio
  • Roller fairlead
Brake System: Spring-Applied, Hydraulic Release Multi-Disc
Maximum Input Flow: 15 gpm/57 lpm
Winch Model: SI 12000
Standards Compliance: SAE J706 / EN 14492-1. CE Directives--Machinery 2006/42/EC; Noise Emission 2000/14/EC; Electromagnetic Compatibility 2014/30/EC
Rope Attachment: Quad-drilled (Left-hand or Right-hand winding drum) Provides flexibility to mount winch in the best orientation
Recommended Rope: 3/8" (SAE J706) 11 mm (EN 14492-1)
Motor Type: 120 cc Hydraulic Gear Motor
Minimum Rope Breaking Strength: 15100 lbs. (SAE J706); 106.8 kN (EN 14492-1)
Maximum Input Pressure: 2300 psi/158 bar
Material: Steel
Can Ship By Ground Delivery: No
Lubrication: Synthetic Grease
Load Block: Superblock Bi-Directional Load Control Valves
Gear System: 2-stage planetary
Gear Ratio: 16:1
Finish: Powder Coated
EN Compliant: Yes
Drum Barrel Diameter: 3.9 in. / 99 mm
Color: Blue Gray
Clutch: Multi-Position Manual Pull-and-Turn
Winch Series: SI Hydraulic Series
