Spicer 706999-14X - Differential Ring and Pinion Kit - DANA 70HD - 7.17 Ratio

Spicer  |  SKU: FSGR-706999-14X
Sale price $1,18999 Regular price $1,60508

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


AVAILABILITY: This Item Is Out Of Stock.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Spicer 706999-14X - Differential Ring and Pinion Kit - DANA 70HD - 7.17 Ratio

Differential Ring and Pinion Kit - DANA 70HD - 7.17 Ratio

Demand genuine Spicer. Made in the USA and complete with all the components needed for the repair. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver. Spicer gearing offers the easiest possible set-up, a quieter ride and strength that cannot be beaten. All gears go through a rigorous production to ensure quality. Statistically controlled heat treatment optimal hardness. Three axis face hobbing reduces noise, vibration and harshness while delivering the smoothest possible ride. Shot Peening doubles fatigue life by shooting micro beads at the root of the tooth. Gears are luberized by adding a chemical finish to remove the break in period other aftermarket gears require.

  • Precision manufacturing processes.
  • Superior Metallurgy: Ensures More Consistent, Higher Quality Product.
  • High-grade quality material for maximum durability.
  • All Spicer ring gear and pinion sets are designed and tested to meet original equipment specifications.
Axle Model: DANA 70
Gear Ratio: 7.17
Ring Teeth Count: 43
Carrier Breaks: 4.56 And Up
Cover Bolt Quantity: 10
Include Installation Kit: Y
On Vehicle Location: Rear
Pinion Gear Tooth Quantity: 6
Pinion Shaft Diameter: 1.750
Pinion Spline Count: 29
Ring Gear Bolt Qty: 12
Ring Gear Bolt Thread In.: .500-20
Ring Gear Diameter (In.): 10.500
Ring Gear Rotation: Standard
Axle Type: Full Floating
New Or Remanufactured: New
Pinion Gear Included: Y
Ring Gear Included: Y
Pinion Nut Included: Y
