MSD 8222 - Blaster High Vibration Ignition Coil

MSD 8222 - Blaster High Vibration Ignition Coil

Ignition Coil - Blaster High Vibration - Canister - Epoxy Filled - 0.700 ohm - Female Socket - 45000V - Black - Each

Blaster High Vibration Ignition Coil; 8 mH Inductance; 45000 Max Voltage; 140 MA Peak Current; 350 uS Spark Duration; 100L1 Turns Ratio; Black;

The sturdy metal housing of the High Vibration Coil is completely potted with a premium grade epoxy to completely encase the coils primary and secondary windings. In applications such as off-road, marine, or other harsh conditions, the MSD Blaster High Vibration Coil is the best choice. This protects the coils internal components from high and low-frequency vibrations that are commonly experienced in racing. The Blaster Coil is designed to mount in most factory canister coil mounts. MSD also offers a Chrome Coil Bracket, PN 8213. It is recommended to mount the PN 8202, PN 82023, and 8223 coils in an upright position. The High Vibration Coil, PN 8222, can be mounted in any position due to its epoxy potting compound.

• Encased w/epoxy to protect windings from high vibrations
• Improved output coil for electronic ignitions and MSD Ignitions
• 100:1 Turns Ratio
• Lower Primary Resistance Produces High Voltage Output
• CARB E.O. Approved
