Mishimoto MMFS-INT-90 - 90-93 Acura Integra Aluminum Fan Shroud Kit
Performance Aluminum Fan Shroud Kit, fits Acura Integra 1990-1993
High-performance component designed to enhance thermal efficiency, durability, and reliability under demanding conditions. Engineered to support optimal temperature control and system performance across applications.
The Mishimoto Acura Integra aluminum fan shroud kit will considerably improve engine cooling functions and the overall performance of your vehicle.All Mishimoto fan shrouds are significantly lighter than standard fan shrouds.The longevity of your engine depends on keeping your engine running cool, especially during those unbearably hot days.A Mishimoto fan shroud will notably improve engine cooling performance by delivering more air to the Integra aluminum radiator and driving out excess heat.The fan shroud serves another very important purpose: It'secures the fan blades, preventing potential damage to other essential engine components.
- Direct plug-n-play for 1990-1993 Acura Integra
- Includes factory plug for easy installation
- Fits both stock and Mishimoto radiators
Installation Difficulty: 2
Material: Aluminum
TechSpec Engine Codes: B18a1--B17a1
TechSpec Chassis Codes: JDM--DA5 - Integra Txi/Rxi/Zxi/ZX 3dr--DA6 - Integra XSi/RSi 3dr--DA7 - Integra RX/ZX/RXi/ZXi/ZX Extra 4dr--DA8 - Integra XSi 4dr--DA9 - Integra 3dr--DB1 - Integra 4dr--DB2 - '92-'93 Integra 3dr
TechSpec Includes: (1) Aluminum Fan Shroud--(1) 12-inch Slim Electric Fan--Mishimoto Lifetime Warranty
TechSpec Weight (lbs): N/A
TechSpec Note: Compatible with OEM and Mishimoto Radiators.----This is a "race" fan shroud and does not retain AC fan.
TechSpec CFM (Each Fan): 1150
TechSpec Height (in): 13.3
TechSpec Length (in): 15.9
TechSpec Width (in): 3.5
TechSpec Applications: 1992-1993 Acura Integra GSR
SellingPoint01: Direct plug-n-play for 1990-1993 Acura Integra
SellingPoint02: Includes factory plug for easy installation
SellingPoint03: Fits both stock and Mishimoto radiators
SellingPoint04: Maximizes airflow
SellingPoint05: Includes Mishimoto slim fan
SellingPoint06: Includes all mounting hardware
SellingPoint07: Polished aluminum finish
SellingPoint08: Mishimoto Lifetime Warranty
SellingPoint09: N/A
SellingPoint10: N/A
SellingPoint11: N/A
SellingPoint12: N/A
SellingPoint13: N/A
SellingPoint14: N/A
SellingPoint15: N/A
Install Difficulty: 2
Airflow Rate: 1150
Blade Color: Black
Blade Included: Yes
Blade Length: 6
Blade Material: Plastic
Blade Quantity: 10
Blade Type: Straight
Control Module Included: No
Control Unit Included: No
Depth: 3.5
Electrical Or Mechanical: Electrical
Fan 1 Blade Quantity: 10
Fan 1 Diameter: 12
Fan 2 Blade Quantity: 10
Fan 2 Diameter: 12
Fan Clutch Mounted: No
Fan Quantity: 1
Grade Type: Performance
Hardwired Or Plug-In: Plug-In
Height: 13.3
Housing Finish: Aluminum
Maximum CFM: 1150
Motor Included: Yes
Mounting Hardware Included: Yes
Shroud Color: Silver
Shroud Included: Yes
Shroud Material: Aluminum
Width: 3.5
