Mcleod 6330807CM - Disc Street Aluminum Twin Ford 4.6/5.0/5.4l 1 1/8in X 26 Spline 8-bolt crank 0bal 164T

Mcleod  |  SKU: MC-6330807CM
$1,51599 $1,59500

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


AVAILABILITY: This Item Is Out Of Stock.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Mcleod 6330807CM - Disc Street Aluminum Twin Ford 4.6/5.0/5.4l 1 1/8in X 26 Spline 8-bolt crank 0bal 164T

Street Twin;Ford;4.6L 8 Bolt;Alum Flywheel;164T;1-1/8 x 26 Spline;Ceramic;Each

McLeod Original Street Twin Kit w/ Steel Flywheel - 1996-2004 Ford Mustang 4.6L 8 Bolt Crank, 1-1/8 x 26 Spline, 164T, Cable Linkage to T-56 Magnum

In 1974 with the rising popularity of power adders such as Nitrous, Superchargers and Turbochargers, McLeod recognized the need for a clutch assembly that was street friendly, yet still capable of handling up to 1,200 horsepower, and 1,500 horsepower with the ceramic disc upgrade and thus the Street Twin was born! This series of McLeod clutch kit is intended for high horsepower street enthusiast. Whether it's NOS, Supercharger, Turbocharger or a Big Inch mountain motor the "Original Street Twin" can handle it. Go with the innovator not the imitator McLeod Racing!

  • •Designed for high-horsepower street vehicles •Available with organic or ceramic friction discs •Includes performance aluminum or steel flywheel •Excellent balance of holding power and street drivability •Strap drive
Make: Ford
Disc Diameter (in.): 10.500
Input Shaft Diameter (in.): 1.125
Input Spline Quantity: 26
Disc Material: Ceramic
Disc Style: Segmented
Hub Style: Solid
Clutch Disc Quantity: 2
Pressure Plate Style: Diaphragm
Horsepower Rating: 1500
Clutch Usage: Performance
Throwout Bearing Included: Yes
Pilot Bushing Included: No
Alignment Tool Included: Yes
Flywheel Included: Yes
Flywheel Material: Billet aluminum
Crankshaft to Flywheel Bolt Quantity: 8-bolt
Engine Balance: Internal
Ring Gear Tooth Quantity: 164-tooth
Hardware Included: Yes
Quantity: Sold as a kit.
Notes: Cable Linkage to T-56 Magnum: Tremec changed the ball stud location on the T-56 Magnums for the Ford application. This ball stud change effects the fork angle and TO bearing clearance, causing a pre-load issue on the fingers of the pressure plate. This clutch kit eliminates this issue by giving the customer more clearance with a shorter crank to finger stack height. This kit is specific to 1996-2004 4.6L/5.0L Mod Motors with 8 bolt cranks and Tremec T-56 Magnums using cable linkage.
