Mahle Motorsport 930207540-1 - SMALL BLOCK CHEVY 23 degree DOME SINGLE PISTON (930207540) 4.040 x 1.550CH, 3.480/3.500stroke,5.700rod,0.927pin,11.1cc,525g
Mahle Motorsport | SKU:
DGJH-930207540-1
Regular price
$000
Unit price
/
Unavailable
AVAILABILITY: This Item Is No Longer Orderable. Contact Us For More Details.
Couldn't load pickup availability
PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.
Description
Description
Mahle Motorsport 930207540-1 - SMALL BLOCK CHEVY 23 degree DOME SINGLE PISTON (930207540) 4.040 x 1.550CH, 3.480/3.500stroke,5.700rod,0.927pin,11.1cc,525g
Mahle Motorsport Engine Piston
SMALL BLOCK CHEVY 23? DOME SINGLE PISTON (930207540) 4.040 x 1.550CH, 3.480/3.500stroke,5.700rod,0.927pin,11.1cc,525g.
Clip Style: Round Wire
Clips Included: N
Crown Vol: 11.1cc
Package Qty: Sold as a set of 1
Pin Diameter: 0.927
Pin Length: 2.287
Pin Mass: 118g
Pin Material: Steel
Pin Style: Floating
Pins Included: N
Piston Mass: 525g
Piston Material: Forged, 2618
Piston Ring Thickness: 1.0mm, 1.0mm, 2.0mm
Piston Style: Dome, w/ 2 valve reliefs
Rings Included: N
