JE Pistons 206066 - Ford Small Block 4.030in Bore 1.165in CH -5.00 CC Piston Kit

JE Pistons  |  SKU: BHXG-206066
Sale price $62499 Regular price $68749


AVAILABILITY: This Item Is Out Of Stock.


PLEASE NOTE: Pictures may be repsentative of style, rather than the actual product. Read the description for more details.

Description

JE Pistons 206066 - Ford Small Block 4.030in Bore 1.165in CH -5.00 CC Piston Kit

Piston Set, 4032, Flat Top, 4.030 Bore, 1.165 CD, 0.927 Pin, Set of 8.

SRP, Ford, Small Block Ford, 4.030 in. Bore, 1.165 CD, Flat Top, 8 Cyl. Piston Kit

Born from the rich racing experience of JE Pistons, the Sportsman Racing Products (SRP) piston line proudly bridges the gap between high-quality forged piston performance and affordability. Forged from strong, 4032 aluminum alloy material, SRP pistons are designed and manufactured to reduce machining costs without sacrificing strength or performance characteristics. These pistons are the perfect option for someone building a mild to moderate performance engine on a sportsman budget. As with all JE Pistons products, SRP pistons are made 100% in the USA.

    • Forged in the USA using 4032 aluminum, yielding tensile strength and minimal thermal expansion
    • Dedicated forging helps optimize strength and weight throughout the piston design
    • Perfect for street/strip applications
    • Forced pin oiling for improved pin lubrication
    • Made 100% in the USA
Add-On: S100S8-4030-5
Add-On: 927-2750-15-51S
Add-On: 927-042-CS
Bore Diameter - Web: 4.030 IN
Bore Diameter: 4.030
Category Hierarchy: Auto>SRP Pistons>SRP
Compression Height: 1.165
Cylinder Head: SMALL BLOCK FORD 20 DEG
Engine - Web: Small Block
Engine Type: ICE
Engine: Small Block
Forging Type: FSR
Industry: Automotive
Make - Web: Ford
Make: Ford
Oil Ring Thickness: 0.218
Out of Stock Message: Please Allow Approximately 3 Weeks or Less for Shipping
Piston Average Weight: 431
Piston Head Type: Flat
Piston Material: 4032
Piston Series: SRP
Piston Volume: -5.00
Product Market: Domestic
Product Type: Engine Piston Kit
Ring Set Included: No
Second Compression Ring Thickness: 0.0640
Title - Web: SRP Ford Small Block Piston Kit - 4.030 in. Bore - 1.165 in. CH, -5.00 CC
Top Compression Ring Thickness: 0.0640
Wrist Pin Length: 2.750
Wrist Pin Material: 5115 Low Carbon Steel, Case Hardened
Wrist Pin Outer Diameter: 0.927
Wrist Pin Wall Thickness: 0.150
