Icon 91501-CB - 04-08 Ford F-150 2WD 2.5 Custom Shocks VS IR Coilover Kit w/Fabtech 6in

Icon  |  SKU: ICON-91501-CB
Sale price $1,76795 Regular price $1,94474

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


AVAILABILITY: This Item Is Out Of Stock.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Icon 91501-CB - 04-08 Ford F-150 2WD 2.5 Custom Shocks VS IR Coilover Kit w/Fabtech 6in

2004-2008 F150 2WD 2.5 VS INTERNAL RESERVOIR COILOVER KIT W/ FABTECH 6" LIFT

ICON Vehicle Dynamics V.S. Series 2.5" coil-over shocks are an incredible upgrade for the front end of 2004-2008 Ford F-150 2WD trucks equipped with a 6" lift subframe lift kit. ICON's Vehicle-specific valving provide a sport tuned feel on and off-road while lift height adjustability allows the fine tuning of the vehicle's ride height. Their full-length design eliminates the need for top-load coilover spacers that are commonly used with factory length coilovers for these taller lift kits. The larger 2.5" shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. When paired with ICON rear 2.0 Aluminum Series or 2.5 Series shocks vehicle control will be balanced front to rear, resulting in the best overall driving experience for your F-150 truck.

  • Length optimised for pairing with Fabtech 6" lift kits
  • Full length coilovers eliminate need for coilover spacers
  • Increased wheel travel and ride quality
  • Vehicle specific tuned for superior shock damping and control
  • Adjustable lift height
  • ICON engineered coil Springs
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant CAD plated shock body with 7/8" hardened chrome shafts
  • FK rod end bearings for extended longevity and minimal deflection
  • 100% Bolt-on - no drilling,cutting or welding necessary for installation
AAP_UDA_12: EA
AAP_UDA_22: 1
AAP_UDA_4: 55
Active or Passive Suspension: Passive
Add-On Part: 198000 - 2 PIN COILOVER SPANNER WRENCH KIT
Add-On Part: 198001 - BILLET SPANNER WRENCH KIT
Adjustable Compression: No
Adjustable Damping: NO
Adjustable Rebound: No
Adjustable Ride Height: Yes
Assembled: Yes
Body Diameter: 2.5
Coil Over Springs Included: Yes
Cylinder Color: Silver
Cylinder Finish: Cadmium Plated
Cylinder Material: Steel
Damping Type: Oil
Dust Shield Included: No
Extended Length: 26.33
Front Spring Rate: 600
Gas Charged: yes
Grade Type: Performance
Includes Bump Stop: Yes
Internal Construction Type: Single Tube
Lower Mount Type: Eyelet
Material: Aluminum
Material: Steel
Remote Reservoir: NO
Reservoir Style: Internal
Self-Leveling: No
Service Parts: 252001 - 2.5 FIXED SPANNER WRENCH
Service Parts: 611019 - COILOVER HARDWARE KIT PAIR
Service Parts: 252002 - UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0)
Service Parts: 252003 - SEAL INSTALL TOOL 2.5/3.0
Service Parts: 254100G - 1 GALLON ICON PERFORMANCE SHOCK OIL
Service Parts: 252004 - ECONOMY NEEDLE CHARGING TOOL
Service Parts: 252010 - 2.5 IFP REBUILD KIT
Shaft Diameter: 0.875
Shock Absorber Body End Measuring Point: Top of Upper Mount Plate
Shock Absorber Rod End Measuring Point: Center of Eylet
Spring Color: Black
Spring Material: Steel
Spring Rate Type: Linear
Upper Mount Type: Mounting Plate
Valving Type: Digressive
