Hella 002768431 - Horn Disc 24V 400Hz Htone (B36)

Hella  |  SKU: HLA-002768431
Sale price $4599 Regular price $5059

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


AVAILABILITY: This Item Is Out Of Stock.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Hella 002768431 - Horn Disc 24V 400Hz Htone (B36)

HORN 24V 400HZ B36 3BA

The HELLA B36 Series Disc Horn is engineered for durability and performance, providing a reliable safety feature for any vehicle. These disc horns are galvanized to resist corrosion and built to last, with a sound frequency of 335 Hz (Low-Tone), or 400 Hz (High-Tone), ensuring precise and robust auditory signals in all driving conditions. The sleek, compact design allows for versatile installation options, making it an excellent choice for drivers who need a powerful horn without compromising space. Whether navigating busy city streets or rural roads, the HELLA B36 Series enhances your vehicle's audible presence, ensuring you are heard when it matters most. These horns guarantee your highest safety and the attention needed in critical situations. HELLA horns guarantee the best functionality, optimum fit, and long-lasting customer satisfaction.

  • Enhances road safety by emitting a 335 Hz tone, providing clear and audible alerts in all conditions.
  • Delivers maximum awareness with a volume output ranging from 108 dB(A) to 118 dB(A), ensuring audibility.
  • Ensures long-term reliability with robust construction engineered to withstand vibration and harsh conditions.
  • Facilitates fast identification and installation with concise short codes, streamlining maintenance and replacement.
  • Designed for universal compatibility, this part fits most modern vehicles, simplifying the installation process.
Homologation: ECE-R28
Temperature range to [°C]: 60
Mounting Type: with 6.3 mm Blade Terminal Contacts, Open
Frequency Range [Hz]: 400
Temperature range from [°C]: -40
Bracket: M10 Mounting Screw
IP Rating: IP54
Voltage [VDC]: 24
Temperature range to [°C]: 60
Temperature range from [°F]: -40
IP Rating: X9K
ECE Regulation: R28
Supplementary Article/Supplementary Info 2: with E Quality Seal
IP Rating: X4K
Quantity: 1
Signal: High Tone
Temperature range to [°F]: 140
Housing Color: Gray
Test Mark: ECE
Voltage: 24.00
Color: Gray / Black
Decibel Rating: 105.00
Mounting Hardware Included: No
Connector Quantity: 1
Mount Type: Blade Coupling
Terminal Quantity: 2
Mounting Bracket Included: Yes
Measurements [cm]: 5.3 x 12.9
Frequency range to [Hz]: 400
Single Includes: (1) High-Tone Disc Horn, Mounting Brackets, Step-by-Step Mounting Instructions
Wattage [W]: 72
Overall Height [mm]: 129
Diameter [in]: 4.41
Diameter [cm]: 11.2
Assy/Disassy by Qualified Personnel Required!: .
Depth [mm]: 53
Diameter [mm]: 112
Registration Type: ECE Approved
Power consumption [A]: 3
Housing Color: Black / Gray
Mounting Type: Flat Plug-in Connector
Depth [in]: 2.09
Operating Mode: Electric
Overall Height [in]: 5.08
Test Mark: ECE-R28
Sound Level [dB(A)]: 116
Sound Level [dB(A)]: 105
IP Rating: IP5K9K
