Hella 001946082 - Trailer Hitch Plug

Hella  |  SKU: HLA-001946082
$2399 $2639

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


AVAILABILITY: This Item Is Out Of Stock.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Hella 001946082 - Trailer Hitch Plug

HELLA Trailer Hitch Plug 001946082

The tried-and-tested plug-in system according to ISO 4165 allows an additional connection option for supplying a variety of small consumers products. Depending on the version, the plug-in systems can be installed both inside and outside the vehicle. The universal plugs allow the use of both systems with one and the same plug due to the red front adapter. Here, too, the HELLA range offers the right design for almost every application thanks to its wide variety.

  • Easy assembly
Mounting Type: Fitting
Number of pins: 1
Voltage from (V): 6
Supplementary Article/Supplementary Info: with Snap Lid
Voltage to (V): 24
Capacity at 24V: 16A
DIN/ISO Standard: 4165
DIN/ISO: 4165
Plug Type: Blade Terminal
Color: Black
Current Strength (A): 16
Inner diameter (mm): 12
Inner Diameter (in): 0.47
Temperature range from (C): -40
Temperature range from (F): -40.00
Temperature range to (C): +80
Temperature range to (F): 176.00
Length (mm): 43.5
Socket Width (mm): 6.3
Fitted Diameter (mm): 18.5
Assy/Disassy by Qualified Personnel Required!: .
Quantity: 10
