Hedman Hedders 68150 - HEDMAN HEADERS 1968-72 CHEVELLE/EL CAMINO (AND RELATED A-BODIES) LS SWAP HEADERS; AUTO TRANSMISSION; 1-3/4 IN. LONG TUBE; 3 IN. BALL/SOCKET COLLECTOR- UNCOATED

Name: Hedman Hedders 68150 - HEDMAN HEADERS 1968-72 CHEVELLE/EL CAMINO (AND RELATED A-BODIES) LS SWAP HEADERS; AUTO TRANSMISSION; 1-3/4 IN. LONG TUBE; 3 IN. BALL/SOCKET COLLECTOR- UNCOATED
Brand: Hedman Hedders
SKU: FBLG-68150
Price: 415.99 USD
Availability: InStock

Hedman Hedders | SKU: FBLG-68150

$415⁹⁹ $1,009⁷⁷

PLEASE NOTE: Pictures may be repsentative of style, rather than the actual product. Read the description for more details.

Description

Hedman Hedders 68150 - HEDMAN HEADERS 1968-72 CHEVELLE/EL CAMINO (AND RELATED A-BODIES) LS SWAP HEADERS; AUTO TRANSMISSION; 1-3/4 IN. LONG TUBE; 3 IN. BALL/SOCKET COLLECTOR- UNCOATED

Headers - Long Tube - 1.75 in Primary - 3 in Collector - Long Tube - Gaskets / Hardware Included - Steel - Black Ceramic - GM LS-Series - GM A-Body 1968-72 - Pair

Hedman Hedders 1968-72 Chevelle/El Camino (and related A-Bodies) LS Swap Headers; Auto Transmission; 1-3/4 in. Long Tube; 3 in. Ball/Socket Collector- Uncoated Mild Steel

Handcrafted, Mild Steel Construction.
Long Tube Header Design Provides Excellent Top-End Horsepower and Torque.
Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
Proud To Say, Made In The USA, Since 1954!

Variations: 68150, 68153, 68156, 62150, 62156 & 62153.

Tube Material Thickness: 16g

Tube Style: Long Tubes

Contents: Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware

Air Conditioning: Yes

Automatic Transmission - Column: Yes

Automatic Transmission - Floor: Yes

Manual Transmission - Column: No

Manual Transmission - Floor: No

Power Steering: Yes

Collector Attachment: 3 in.

Collector Diameter: 3 in.

Collector Size: 3 in.

Collector Style: BALL and SOCKET Style (Gasketless)

Reducer Outlet Size: 2-1/2 in.

Exhaust System Dia: 2-1/2 in.

E.O. #: No

Tube Length: Long Tubes

Emissions Notes: Not Legal For Street Use on '75-Later Model Years! Legal for off-road use only.

Engine: Chevy LS Series

Finish: Uncoated

Finish Type: UNCOATED Mild Steel! Shipped with Temporary Paint.

Flange Style: ELITE

Flange Thickness: 0.375 in.

Product Type: Headers

Header Port Shape: Round

Header Style: Long Tube

IMPORTANT!: Automatic Transmission ONLY!

Port Shape: Round

Material: Mild Steel

Tube Design: Standard

Tube Diameter: 1-3/4 in.

Reducers Included: Yes

Installation Notes: Requires Trans-Dapt Engine Swap Mount Kit 4600 (TH350/700R4) or 4601 (4L60/70E)

with A.I.R. System: No

with EGR: No

Weld-Up: No

Tuned: No

Bolts/Studs Included: Yes

Catalytic Converter(s) Included: No

Collector Bolts Included: Yes

Crossover Pipe Included: No

Gasket Or Seal Included: Yes

Header Fasteners Included: Yes

Installation Hardware Included: Yes

Y-Pipe Included: No

Tube Size: 1-3/4 in.

Quantity: Sold as a pair.

Primary Tube Gauge: 16g

Primary Tube Diameter (in): 1.75 in.

Package Contents: Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware

Header Material: Mild Steel

Header Finish: Uncoated

Cylinder Head Port Shape: Round

Cylinder Head: Stock Profile Heads

Vehicle Family: A-Body (GM) 1968-72

Header Construction: MILD STEEL- Standard-Duty

Replacement Gasket: 27470

Hedman Hedders 68150 - HEDMAN HEADERS 1968-72 CHEVELLE/EL CAMINO (AND RELATED A-BODIES) LS SWAP HEADERS; AUTO TRANSMISSION; 1-3/4 IN. LONG TUBE; 3 IN. BALL/SOCKET COLLECTOR- UNCOATED
