Edelbrock 77589 - Victor Jr # Small-Block Chevy 64cc Hydraulic Roller Camshaft

Edelbrock  |  SKU: EDEL-77589
$1,21495 $1,33644

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


AVAILABILITY: This Item Is Out Of Stock.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Edelbrock 77589 - Victor Jr # Small-Block Chevy 64cc Hydraulic Roller Camshaft

Victor Jr #77589 Small-Block Chevy 64cc Hydraulic Roller Camshaft

Edelbrock part #77589 Victor Jr. is a complete cylinder head for Small Block Chevy 262-400 V8 engines using a hydraulic roller cam. This cylinder head offers affordable max power for competition and high-performance's street applications

The Edelbrock part #77589 Small Block Chevy Victor Jr. 215cc cylinder head is an affordable version that will still allow for maximum power when used in competition and ultra high-performance's street applications. This cylinder head has the potential of 530-580 hp out-of-the-box, for a cost effective, race-winning set-up. These cylinder head features angled spark plug holes and accept standard 23deg valvetrain hardware. The 77589 cylinder head has a 64cc combustion chamber and come with springs for hydraulic roller camshafts. The 64cc chambers yield about 12.5:1 compression with a 12cc domed piston in a 350 V8.

  • Out-of-the-Box Bolt-On Performance
  • Affordable; Top Quality
  • Race-Winning Set-Up
  • Accepts Standard 23 Deg. Valvetrain Hardware
  • 64cc Chamber Ideal for Entry Race/Hi-End Street
Exhaust Runner Volume: 85
Family: Victor Jr.
Rocker Arm Stud Diameter: 0.4375
Quantity: Sold Individually
Retainer Included: Yes
CNC Ported: No
Exhaust Port Location: +.125
Valve Angle: 23
Camshaft Type: Hydraulic Roller
Push Rod Diameter: (Suggested) 0.5625
Rotor Center Bore Inside Diameter: angled
Deck Thickness: 0.5625
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Intake Valve Diameter: 2.08
Exhaust Valve Diameter: 1.60
EGR Port: No
Series: Victor Jr.
Construction Type: Complete
Guide Material: Manganese Bronze
Valve Stem Diameter: 0.3438
Seat Material: Ductile Iron
Valve Spring Maximum Lift: 0.650
Horsepower: 450-550
Valve Spring Diameter: 1.55
Seat Angle: Exhaust 45 deg/Intake 45
Valve Springs Included: Yes
Valve Spring Retainers Included: Yes
Valve Seals Included: Yes
Valve Locks Included: Yes
Valve Lock Material: Chromoly Steel
Valve Cover Gasket Included: No
Rocker Arms Included: No
Rocker Arm Studs/Bolts Included: Yes
Mounting Hardware Included: No
Material: Aluminum
Intake Runner Volume: 215
Head Casting Number: 31-7763
Guide Plates Included: Yes
Guide Plate Material: Chromoly Steel
Grade Type: Performance
Deck Height: 9.025
Cylinder Head Gasket Included: No
Combustion Chamber Volume: 64
Assembled: Yes
Valves Included: Yes
Valve Lock Material: Steel
Guide Plate Material: Hardened Steel
