Edelbrock 61857 - Cylinder Head Ford FE Pro-Port NHRA Super Stock

Edelbrock  |  SKU: EDEL-61857
Sale price $86699 Regular price $95369

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Edelbrock 61857 - Cylinder Head Ford FE Pro-Port NHRA Super Stock

Performer Series RPM NHRA Super Stock Cylinder Head

The Edelbrock 61857 Ford FE NHRA Pro-Port Cylinder head is designed specifically for the professional cylinder head porter and engine builder. Like the other Edelbrock Cylinder head, The Pro-Port cylinder head is also cast in the USA at the state-of-the-art Edelbrock Foundry with extra-thick walls to allow for custom CNC porting. In most cases, seats and manganese-bronze valve guides are included, but not installed. Please note: This head can not be used without professional head preparation. Pro-Port RAW Features Include: - Unported versions of Edelbrock race-winning Victor Series CNC head for the professional cylinder head porter and engine builder - The Pro-Port cylinder head is cast in the USA at the state-of-the-art Edelbrock Foundry with extra-thick walls to allow for custom CNC porting - The only head designed specifically to accommodate almost any CNC port shape, size or location - Offers enough wall thickness for CNC machining to various port dimensions - In most cases seats and manganese-bronze valve guides are included - Some of the Edelbrock Pro-Port Raw Head Feature Our Special Hot Isostatic Pressing or HIP Process.

  • Undersized As Cast Ports For Custom CNC
  • Fits 48-Pin Connector Type ECU
  • Ductile Iron Seats
Material: Aluminum
Mounting Hardware Included: No
Head Casting Number: 27-6185
Guide Plates Included: No
Grade Type: Performance
Deck Height: 10.17
Cylinder Head Gasket Included: No
Combustion Chamber Volume: 45
Assembled: No
Valves Included: No
Exhaust Valve Pierce Points (X,Y)(C): 1.160 in, 0.220
Seat Angle: Exhaust 45 deg/Intake 60
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Valve Guides Included: Yes
Intake Valve Diameter: (Suggested) 2.09
Exhaust Port Entry: 1.55 in x 1.00
Intake Valve Pierce Points (X,Y)(C): 0.885 in, 0.220
Seat Material: Ductile Iron
Combustion Chamber Volume: Possible 45
Valve Angle: 13
Guide Material: Manganese Bronze
Valve Seats Included: Yes
Valve Spacing: 2.045
Quantity: Sold Individually
EGR Port: No
Family: Performer RPM
Specialty: Hot Isostatic Pressing (HIP) Processing
Series: Pro-Port
Construction Type: Pro-Port Raw
CNC Ported: No
Intake Port Entry: 1.49 in x 0.94
Retainer Included: No
Deck Thickness: 0.625
Exhaust Valve Diameter: (Suggested) 1.66
Valve Springs Included: No
Valve Spring Retainers Included: No
Valve Seals Included: No
Valve Locks Included: No
Valve Cover Gasket Included: No
Rocker Arms Included: No
Rocker Arm Studs/Bolts Included: No
