Edelbrock 61189 - Single Victor Jr 170cc CNC 426-572 Hemi Bare Head w/ Valves

Edelbrock  |  SKU: EDEL-61189
$1,73695 $1,91064

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Edelbrock 61189 - Single Victor Jr 170cc CNC 426-572 Hemi Bare Head w/ Valves

Victor Jr Gen II HEMI Chrysler Cylinder Head CNC W/ Valves

Our new Edelbrock #61189 Victor Jr. Cylinder Heads are designed for high output 650+ hp Chrysler 426-572 HEMI engines. Fully CNC'd combustion chambers and CNC blended seats for optimal air flow performance.

Our new Edelbrock #61189 Victor Jr. cylinder head is designed for high output 650+ hp Chrysler 426-572 HEMI engines. They feature fully CNC'd combustion chambers and CNC blended seats for optimal air flow performance. This cylinder head also feature a revised exhaust valve angle to accommodate larger intake valves. They also feature brass tubes installed in exhaust pushrod holes to allow maximum clearance with minimal port intrusion.

  • CNC Chambers
  • CNC Blended Valve Seats
  • Revised Exhaust Valve Angle
Deck Thickness: 0.625
Mounting Hardware Included: No
Valve Springs Included: No
Valve Spring Retainers Included: No
Valve Seals Included: No
Valve Locks Included: No
Valve Cover Gasket Included: No
Rocker Arms Included: No
Rocker Arm Studs/Bolts Included: No
Assembled: No
Material: Aluminum
Intake Runner Volume: 245
Head Casting Number: 31-6117
Guide Plates Included: No
Grade Type: Performance
Deck Height: 10.72
Cylinder Head Gasket Included: No
Combustion Chamber Volume: 170
Valves Included: Yes
Quantity: Sold Individually
Valve Stem Diameter: 0.3125
CNC Ported: Yes
Exhaust Port Location: Standard
Seat Angle: Exhaust 45 deg/Intake 45
Exhaust Runner Volume: 105
Construction Type: Bare With Valves
Exhaust Valve Diameter: 1.94
Guide Material: Manganese Bronze
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Seat Material: Ductile Iron
Intake Valve Diameter: 2.320
Valve Angle: Exhaust (Tipped) 1.5-21.5 deg/Intake Stock
EGR Port: No
Series: Victor Jr.
Family: Victor Jr.
Retainer Included: No
