Edelbrock 60559 - Single Perf RPM BBC Rect Port Head Comp

Edelbrock  |  SKU: EDEL-60559
Sale price $1,36199 Regular price $1,49819

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Edelbrock 60559 - Single Perf RPM BBC Rect Port Head Comp

Cylinder Head - Performer RPM - Assembled - 2.190 / 1.880 in Valves - 315 cc Intake - 118 cc Chamber - 1.550 in Springs - Angle Plug - Aluminum - Big Block Chevy - Each

The Edelbrock #60559 Performer RPM Rectangle Port cylinder heads are designed for BB Chevy engines. The Edelbrock #60559 Performer RPM heads are perfect for street performance, daily drivers and muscle cars where more performance is needed.

The Edelbrock #60559 Performer RPM Rectangle Port cylinder head is designed for Big-Block Chevy applications. The Edelbrock #60559 Performer RPM head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. This cylinder head delivers great throttle response and power from 2500 to 7000 rpm. They also feature the highest quality intake and exhaust valves and valve springs. For use on pre-pollution controlled vehicles only.

  • Smaller-Than-Stock 11/32 in. Valve Stems Promote Excellent Flow
Deck Thickness: 0.5625
CNC Ported: No
Intake Valve Diameter: 2.19
Quantity: Sold Individually
Retainer Included: Yes
Rocker Arm Stud Diameter: 0.4375
Valve Stem Diameter: 0.3438
Valve Spring Maximum Lift: 0.700
Horsepower: 525-650
Valve Angle: 26
Seat Angle: Exhaust 45 deg/Intake 45
Exhaust Port Location: Standard
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Series: Performer RPM
Valve Spring Diameter: 1.50
EGR Port: No
Exhaust Runner Volume: 110
Family: Performer RPM
Seat Material: Ductile Iron
Construction Type: Complete
Push Rod Diameter: (Suggested) 0.4375
Guide Material: Manganese Bronze
Mounting Hardware Included: No
Valve Springs Included: Yes
Valve Spring Retainers Included: Yes
Valve Seals Included: Yes
Valve Locks Included: Yes
Valve Lock Material: Chromoly Steel
Valve Cover Gasket Included: No
Rocker Arms Included: No
Rocker Arm Studs/Bolts Included: Yes
Material: Aluminum
Assembled: Yes
Intake Runner Volume: 315
Head Casting Number: 31-6055
Guide Plates Included: Yes
Guide Plate Material: Chromoly Steel
Grade Type: Performance
Deck Height: 10.2
Cylinder Head Gasket Included: No
Combustion Chamber Volume: 118
Valves Included: Yes
Valve Lock Material: Steel
Guide Plate Material: Hardened Steel
Camshaft Type: Flat Tappet
Exhaust Valve Diameter: 1.88
