Edelbrock 28945 - Intake Manifold Victor Jr Holden V8 VN EFI Single Plane 4150 Throttle Body

Edelbrock  |  SKU: EDEL-28945
$71395 $78534

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

PLEASE NOTE: Pictures may be repsentative of style, rather than the actual product. Read the description for more details.

Description

Edelbrock 28945 - Intake Manifold Victor Jr Holden V8 VN EFI Single Plane 4150 Throttle Body

Victor Jr. Series Intake Manifold

Edelbrock Victor Jr Holden Intake Manifold EFI

Edelbrock part #28945 Victor Jr. Holden EFI intake manifold is for use with competition 355+ c.i.d. Holden V8 engines that utilize the 1988-98 Holden VN cylinder heads. The Victor Jr. Holden is a single-plane design that is tuned for maximum air flow from 3500 to 7500 rpm. It features a taller design with long tapered runners for a broad operating rpm range. Will fit both stock 1988-1998 EFI style cylinder heads and the Edelbrock Holden VN RPM cylinder heads. It also features a 4150 flange for use with square-bore carburetors and throttle bodies. Includes extra material for porters to modify for use with 4500 series applications. The water outlet is machined for use with a small-block Chevy waterneck.

  • For Use w/Competition 355+ cid Holden V8
  • With 1988-1998 Holden VN Cylinder Heads
  • Taller Designer w/Long Tapered Runners
Gasket Or Seal Included: No
Basic Operating RPM Range: 3500-7500
Material: Aluminum
Grade Type: Performance
Single Or Dual Plane Type: Single
Center Maximum Height: 6.950
CNC Ported: No
Vehicle Model: Holden
Rear Maximum Height: 6.950
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Finish: Satin
Flange Type: 4150
Series: Victor
Front Maximum Height: 6.950
EGR Port: No
