DS18 SRW10.4D - SRW Shallow 10 Inch Subwoofer 700 Watts Dvc 4-Ohm
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
Description
Description
DS18 SRW10.4D - SRW Shallow 10 Inch Subwoofer 700 Watts Dvc 4-Ohm
It's easy to get great bass when there's very little room with our new line of slim mount subwoofers. The SRW 10.4D (DVC) and SRW 10.4 (SVC) mounts in little as 3.15 inches mounting depth and can be utilized in both ported and sealed boxes for great bass in a tight area.
This sub handles 200 watts RMS and 400 watts peak power with a 90 db sensitivity which is very high for a slim mount sub raising this model high above the bar.
This sub comes in both dual voice coil 4 ohm (SRW 10.4D) and single voice coil 4 ohm (SRW 10.4) so you can wire appropriately to your amp for maximum power to bring all your music to life!
Key features
- Rubber surround and plastic cone for long lasting life and durability.
- High strength aluminum 2 inch voice coil to maximize cooling efficiency and great power handling.
- Mounts in a very shallow depth of 3.15 inches so you can fit this sub almost anywhere.
- Works great in ported and sealed boxes for tight thumping bass
Details:
- Nominal Diameter 10 inch
- Nominal Impedance 4+4 ohms
- RMS Power Handling 200 Watts
- Maximum Power Handling 400 Watts
- Sensitivity (1w/1m) 89dB
- Frequency Response 424.2Khz
- Recommended Lo Pass Crossover 80Hz
- Voice Coil Diameter 50.8mm / 2 inch
- Voice Coil Former Material Aluminum
- Winding Material SV
- Basket Material Steel Basket
- Frame Material Steel Basket
- Magnet Weight Ferrite 45 oz
Measurements
- Overall Diameter 260mm / 8.42 inch
- Front Mount Baffle Cutout 232mm / 7.12 inch
- Over Depth 93mm / 3.34 inch
- Mounting Depth 80mm / 2.83 inch
