DS18 PRO-TWX6 - PRO 1.5 Inch VC Aluminum Super Bullet Tweeter 480 Watts 8-Ohm
DS18's new 8 ohm super tweeter is sleek and refined after many years of testing and development. These square aluminum housings hold a titanium 1.5 inch voice coil rated for 240w Program power and 480w MAX power with a ferrite motor structure.
With a 112db sensitivity rating, these tweeters do not need a lot of power to get extremely loud. These tweets have a range of 1.7hz to 20khz so you will be sure you wont miss one crack of the high hat!
Key Features
- Sturdy 4x4 aluminum throat for easy mounting and aesthetic symmetrical look.
- 112db sensitivity with a 240w program and 280w peak power rating.
- Mounting depth of 2.75 inches so they will clear most door panel locations with minimal fabrication work.
- Silver bullet resonator helps clear and loud frequencies to carry through the air.
- Nominal Diameter 4 inchx4 inch / 102x102mm
- Nominal Impedance 8 ohms
- Peak Power 480 watts
- Program Power 240 watts
- AES Power 120 watts
- Sensitivity (1w/1m) 112 db
- Frequency Response 1.7Hz-20KHz
- Recommended Hi Pass Crossover 2.5hz
Motor:
- Voice Coil Diameter 1.5 inch / 38mm
- Voice Coil Former Material KSV
- Winding Material SN
- Diaphragm Material Titanium
- Body Material Aluminum
- Magnet Material Ferrite
- Magnet Weight 15 oz
Measurements:
- Overall Diameter 4 inchx4 inch / 102x102mm
- Front Mount Baffle Cutout 3.5 inch / 90mm
- Overall Depth 2.7 inch/ 69mm
- Mounting Depth 2.5 inch / 65mm
- Motor Diameter 3.5 inch / 90mm
