DS18 PRO-DR1P - PRO 1 Inch Twist On Throat Compression Driver W/ 1 Inch Phenolic Voice Coil 240 Watts 8-ohm
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
Couldn't load pickup availability
Description
Description
DS18 PRO-DR1P - PRO 1 Inch Twist On Throat Compression Driver W/ 1 Inch Phenolic Voice Coil 240 Watts 8-ohm
Screaming onto the scene is DS18's PRO-DR1P that has an all new design and has been tweaked for maximum performance and loudness. This horn driver sports a 1 inch 8-ohm CCA voice coil to absorb the 240w peak power and is designed to really make it loud with efficiency.
This driver has a 103 DB sensitivity so the potential of screaming loudness is easily obtainable with the right combination of power. This driver's frequency range is very wide starting at 800hz all the way up to ear drum shattering 20khz!
The PRO-DR1P is sure to complete your pro audio system and complement all your other speakers with crisp and clear high range sound.
Key Features
- Utilizes a CCA 1 inch voice coil to maximize loudness per watt.
- 240w peak power and 120w program power will make these compliment your entire system
- Removable voice coil so if you happen to need to repair on the go, it can be done in minutes.
- Wide frequency response of 800HZ to 20KHZ so you won't miss one high-hat or cymbal crash.
- Will easily accommodate most screws on throats.
Specifications
- Throat Diameter 1 inch
- Installation Type Screw Down
- Nominal Impedance 8 ohms
- Peak Power Handling 240W
- Program Power Handling 120W
- AES Power 60 W
- Sensitivity (1w/1m) 103dB
- Frequency Response 800Hz-20Khz
- Recommended HI Pas Crossover 900Hz
Motor
- Voice Coil Diameter 1 inch
- Voice Coil Former Material Kapton
- Winding Material CCA
- Diaphragm Material Phenolic
- Magnet Material Ferrite
- Magnet Weight 11oz
Measurements
- Overall Diameter 3.13 inch
- Overall Depth 2.4 inch
- Bolt Type M34
- Mounting Depth 1.79 inch
