Dart 13072143 - Pro1 Chevrolet Big Block Head - 225.00 CC Port, 62.00 CC Chamber

Dart  |  SKU: BGWK-13072143
Regular price $000


AVAILABILITY: This Item Is No Longer Orderable. Contact Us For More Details.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Dart 13072143 - Pro1 Chevrolet Big Block Head - 225.00 CC Port, 62.00 CC Chamber

Dart Pro1 CNC Aluminum Big Block Chevy Cylinder Heads

Serious street performance, mild bracket racing and oval track. Maximum torque and throttle response from 3,500 to 7,800 RPM. Best for 363-427 cubic inch engines. Works with most standard components. Every intake port, exhaust runner, valve bowl, and every combustion chamber is 100% CNC machined on special dedicated PRO1 castings. These heads are ideal for high compression, big cubic inch small blocks and are great for supercharged applications. Exhaust runners are raised .135 in. for improved flow. Manganese Bronze valve guides are used for long life, and hardened valve seats provide durability with unleaded fuels. Features 3.000 in. exhaust bolt pattern. Assemblies include Stainless Steel valves, premium springs, locks, retainers, studs, guide plates and seals.

  • Heads are sold individually
Industry: Automotive
CNC Ported: Yes
Combustion Chamber Volume: 62.00
Exhaust Valve Diameter: 1.600
Intake Valve Diameter: 2.080
Material: RMR Cast Aluminum Alloy
Port Volume: 225.00
Valve Angle: 20
Valve Spring Diameter: 1.550
Valve Spring Maximum Lift: 0.700
Engine Type: ICE
Valve Spring Type: Double
Product Type: Engine Cylinder Head
Make: Chevrolet
Engine: Big Block
Make - Web: Chevrolet
Engine - Web: Big Block
Cylinder Head Series: Pro1
Title - Web: Pro1 Chevrolet Big Block Head - 225.00 CC Port, 62.00 CC Chamber
Category Hierarchy: Heads>Big Block Chevy>Pro1
Cylinder Head Material: RMR Cast Aluminum Alloy
Intake Runner Volume: 225.00
EBAY Category ID: 33617
