COMP Cams 7256-16 - Conical Valve Springs 1.060in/1.390in Dia 485lbs Rated (Set Of 16)

COMP Cams  |  SKU: COMP-7256-16
$43299 $47629

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

COMP Cams 7256-16 - Conical Valve Springs 1.060in/1.390in Dia 485lbs Rated (Set Of 16)

Race Sportsman 1.390" OD Conical Springs, 1.900" Installed Height, 16 Springs

Conical Valve Springs 160 @ 1.900" / 495 @ 1.210"

Revolutionary Advancement In High Performance Spring Technology.

7256-16 Outer Diameter and Inner Diameter and Seat Load Open Load Coil Bind Rate and
Top 1.060" .660" 160 @ 1.900" 495 @ 1.210" 1.165" 485
Bottom 1.390" .990"
Spring Rate: 486
Valve Spring Series: Race Sportsman
Amazon ASIN: N/A
C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for On-Road Vehicles?: Yes
C.A.R.B. Exemption Reason: No impact on pollution output of vehicle.
C.A.R.B. E.O. Number: N/A
Coil Bind Height: 1.16
Compatible .570" Guide Diameter Spring Seats: 4670-16
Compatible Retainer: 788-16
Compatible Shims: 4754
Damper: No
Number of Springs: 1
Outer Bottom Spring Inside Diameter: 0.99
Outer Bottom Spring Outside Diameter: 1.39
Outer Top Spring Inside Diameter: 0.66
Outer Top Spring Outside Diameter: 1.06
Seat Height: 1.9
Seat Pressure: 160
