COMP Cams 7228TSD-KIT - Valve Spring Kit, Conical, .62 5 + Lift, Lt4 Tool Steel Retai Ner
COMP Cams | SKU:
COMP-7228TSD-KIT
Sale price
$70195
Regular price
$77214
Unit price
/
Unavailable
$70.19 off
DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.
AVAILABILITY: This Item Is Out Of Stock.
Couldn't load pickup availability
PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.
Description
Description
COMP Cams 7228TSD-KIT - Valve Spring Kit, Conical, .62 5 + Lift, Lt4 Tool Steel Retai Ner
Conical .625" Max Lift Valve Spring Kit for GM GEN V LT4 w/ Tool Steel Retainers
.625" Lift Conical Spring Kit with Tool Steel Retainers for GM Gen V LT4
Max Lift: 0.625
Small End Outside Diameter: 1.03
ID Big End: 0.918
ID Small End: 0.662
Coil Bind Height: 1.125
Installed Height: 1.8
Seat Pressure: 136
Open Load: 410
Spring Rate: 440
Includes Shims?: Yes
Included Seats: 4680-8
Spring Seat Type: Steel
Includes Retainers?: Yes
Retainer Material: Tool Steel
Damper: No
Valve Spring Series: Conical
Spring Style: Conical
Free Length: 2.109
Includes Seats?: Yes
Number of Springs: 1
Cam Type: Hydraulic Roller
Big End Outside Diameter: 1.286
Machine Work Required?: No
