COMP Cams 26918VCS-KIT - Beehive Valve Spring Kit 0.540in Lift for GM Vortec Hydraulic Rollers

Name: COMP Cams 26918VCS-KIT - Beehive Valve Spring Kit 0.540in Lift for GM Vortec Hydraulic Rollers
Brand: COMP Cams
SKU: COMP-26918VCS-KIT
Price: 379.95 USD
Availability: Backorder

COMP Cams | SKU: COMP-26918VCS-KIT

$379⁹⁵ $417⁹⁴

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

AVAILABILITY: This Item Is Out Of Stock.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

COMP Cams 26918VCS-KIT - Beehive Valve Spring Kit 0.540in Lift for GM Vortec Hydraulic Rollers

SPRING KIT, GM L31 VORTEC CYLINDER HEAD, .510" MAX LIFT, HYD ROLLER

Complete .540" max lift, drop-in valve spring kit for GM L31 Vortec Cylinder Heads

This COMP Cams Valve Spring Kit is designed to maximize the potential of GM L31 Vortec cylinder heads when using a hydraulic roller camshaft. This kit allows up to .540" lift and provides spring rates that can handle significantly more aggressive lobe profiles. This kit has been developed to make your valve train upgrade as easy as possible by combining quality components in a package that does not require any machining! These components will drop right onto stock GM L31 Vortec cylinder heads.

Drop-in valve spring kit for GM L31 Vortec cylinder heads
No machining required
Includes metal body
Viton valve stem seals
.540" max lift

Spring Type: Dual Spring

Valve Spring Style: Beehive

Number of Springs Per Valve: 1

Installed Height (in): 1.7

Load at Installed Height (lbs): 162

Open Height (in): 1.16

Load at Open Height (lbs): 363

Recommended Max Lift (in): 0.54

Outside Diameter of Outer Spring (in): 1.066/1.300

Inside Diameter of Outer Spring (in): .650/.875

Inside Diameter of Inner Spring (in): N/A

Spring Rate (lbs/in): 372

Damper Spring Included: No

Maximum Coil Bind Height (in): 1.1

Valve Spring Finish: Raw

Retainer Material: Chromoly

Lock Style: 7 Degree

Valve Stem Diameter (in): 11/32

Valve Stem Seal Type: Positive Stop

Valve Stem Seal Material: Viton

Integrated Spring Seat: No

Spring Seat OD (in): N/A

Spring Seat Step Diameter (in): N/A

Machine Work Required: No

Quantity: 16

Coil Bind Height: 1.1

Installed Height: 1.7

Installed Pressure: 162

Open Pressure: 372
