COMP Cams 26056-1 - Race Sportsman 1.454" OD Beehive Spring; 1.800" Installed Height; 1 Spring

Name: COMP Cams 26056-1 - Race Sportsman 1.454" OD Beehive Spring; 1.800" Installed Height; 1 Spring
Brand: COMP Cams
SKU: COMP-26056-1
Price: 41.95 USD
Availability: Backorder

COMP Cams | SKU: COMP-26056-1

$41⁹⁵ $46¹⁴

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.

AVAILABILITY: This Item Is Out Of Stock.

PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

COMP Cams 26056-1 - Race Sportsman 1.454" OD Beehive Spring; 1.800" Installed Height; 1 Spring

Race Sportsman 1.454" OD Beehive Spring, 1.800" Installed Height, 1 Spring

Beehive springs are one of the best ways to modernize your valvetrain and free up horsepower. This includes one single valve spring. See our 26056-4 for a pack of 4.

Beehive Shape Reduces Spring and Retainer Weight. Less valve train reciprocating mass in motion. More stability, higher RPM, longer life and more horsepower. Requires less spring pressure for better valve control. Provides a double weight savings, reduces the weight of the spring and allows a smaller, lighter retainer. Unique Design Increases Harmonic Resistance, Yielding Greater Spring Stability. Handles valve train stress more efficiently. Increases harmonic resistance for greater stability. Eliminates damaging harmonics. Increases high RPM horsepower and durability.

Compatible .570" Guide Diameter Spring Seat: 4696-1

Valve Spring Series: Race Sportsman

Amazon ASIN: B002EE24OA

C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.

C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for On-Road Vehicles?: Yes

C.A.R.B. Exemption Reason: No impact on pollution output of vehicle.

C.A.R.B. E.O. Number: N/A

Outer Bottom Spring Outside Diameter: 1.454

Spring Rate: 400

Seat Pressure: 160

Seat Height: 1.8

Outer Top Spring Outside Diameter: 1.185

Outer Top Spring Inside Diameter: 0.731

Outer Bottom Spring Inside Diameter: 1

Coil Bind Height: 1.1

Number of Springs: 1

Damper: No

Compatible Spring Cup (O.D. Locator): 4704-1

Compatible Shims: 4757

Compatible Retainer: 785-1

Compatible .630" Guide Diameter Spring Seat: 4697-1
