COMP Cams 20-813-9 - Camshaft CRS XR286HR-10

COMP Cams  |  SKU: COMP-20-813-9
$56699 $62369
PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

COMP Cams 20-813-9 - Camshaft CRS XR286HR-10

Camshaft - Xtreme Energy - Hydraulic Roller - Lift 0.544 / 0.541 in - Duration 286 / 294 - 110 LSA - 2500 / 6200 RPM - Small Block Mopar - Each

3.91+ gears, 2800+ stall, 9.5:1 compression, needs headers, rough idle, street strip.

Featuring a quicker valve opening, the Xtreme Energy camshaft profile provides increased responsiveness and more area under the lift curve than older, slower grinds. Designed to increase performance without sacrificing driveability and creature comforts, the Xtreme Energy grind family offers gains in torque and horsepower while still delivering adequate vacuum for power brakes and other vacuum dependent accessories. Xtreme Energy camshafts work great in carbureted applications, but offer the best performance with aftermarket intake manifolds, lower gear ratios, headers and free flowing exhaust.

Camshaft Series: Xtreme Energy
Usage: Street/Performance
Basic Operating RPM Range: 2,500-6,200
Lifters Included: No
Assembly Lubricant Included: No
Camshaft Material: Billet Steel
Engine Family: Chrysler 273-360 c.i. 8 Cylinder (1964-2002)
Amazon ASIN: B001GBRPGY
C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
C.A.R.B. Exempt for On-Road Vehicles?: No
C.A.R.B. Exemption Reason: N/A
C.A.R.B. E.O. Number: N/A
Grind Number: XR286HR-10
Camshaft Gear Attachment: 1-Bolt
Cam Type: Hydraulic Roller
Camshaft Gear Attachment: 1
Valve Springs Required: Yes
Lifter Type: Hydraulic Roller
Intake Duration at .050 Inch Lift: 236
Exhaust Duration at .050 inch Lift: 242
Advertised Intake Duration: 286
Advertised Exhaust Duration: 294
Lobe Separation: 110
Intake Valve Lift: 0.544
Exhaust Valve Lift: 0.541
