Canton 16-100 - Oil Pan Small Block Chevy S10 Truck Conversion Black Powder Coat

Canton  |  SKU: BGTF-16-100
$39500 $47400
PLEASE NOTE: Pictures may be repsentative of style, rather than the actual product. Read the description for more details.

Description

Canton 16-100 - Oil Pan Small Block Chevy S10 Truck Conversion Black Powder Coat

Engine Oil Pan - Truck - Rear Sump - 7 qt - 10 in Deep - Steel - Black Powder Coat - 2-Piece Seal - S-10 Engine Swap - Small Block Chevy - Each

Canton 16-100 Oil Pan Small Block Chevy S10 Truck Conversion Black Powder Coat

This SBC S-10 V-8 conversion oil pan is for pre-'86 blocks. It is designed to install a Chevy small block into the popular S-10 / S-15 pickup & Blazer 4x4 chassis when used in conjunction with Hooker Mount #12610 and Hooker Headers #2839. The 10" deep sump gives a 7 quart system capacity. This pan requires a M210S or M211S pickup.

  • Designed for 5.0 Coyote Blocks
  • Diamond Shape Road Race Baffle Assembly With Four Trap Doors
  • Removable Windage/Anti-Slosh Baffle
  • 1/2" NPT Temperature Bung
  • 20mm Bung for low Oil Warning Sender
  • Made In USA
  • Tig Welded
Baffled: Yes
Hardware Included: No
Sump Width: 7.75 inches
Sump Depth: 10 inches
Stoke: 3.875 inches
Recommended Accessory 3: 88-100 - SBC Pre ?85 Oil Pan Gasket
Recommended Accessory 2: 20-854 - Universal Steel Braided Dipstick Kit 1/4" N.P.T. Fitting
Recommended Accessory 1: 20-850 - Universal Dipstick Kit 1/4" N.P.T. Fitting
Pickup Included: No
Material: Steel
Kicked Out: Yes
Gasket or Seal Included: No
Capacity: 7 Quart System Capacity
Finish: Black Powdercoat
Feature 6: Magnetic Drain Plug
Feature 5: Provision For Our Pan Mounted Dipstick
Feature 4: Built In Screen Windage Tray
Feature 3: Slosh Baffle
Feature 2: Crank Scraper
Feature 1: 7 qt System Capacity
Drain Plug Included: Yes
Dipstick Port: Yes
Crank Scraper Included: Yes
Windage Tray Included: Yes
