Canton 15-774 - Oil Pan Big Block Ford Rear T Rear Sump Road Race Pan

Canton  |  SKU: BGTF-15-774
$49900 $59880


AVAILABILITY: This Item Is Out Of Stock.

PLEASE NOTE: Pictures may be repsentative of style, rather than the actual product. Read the description for more details.

Description

Canton 15-774 - Oil Pan Big Block Ford Rear T Rear Sump Road Race Pan

Engine Oil Pan - Street / Strip / Road Race - Rear Sump - 7 qt - 7.5 in Deep - Steel - Cadmium - Big Block Ford - Each

Canton 15-774 Oil Pan Big Block Ford Rear T Rear Sump Road Race Pan

This ?T? style rear sump road race baffled oil pan is designed for Ford 429-460 engines in ?79 and up Mustangs and other rear sump applications, such as Cobra Kits. It has a 7-1/2" deep by 8" long by 13-1/2" wide sump with a 7 quart system capacity. This pan requires our 15-775 pickup & M84DHV Oil pump.

  • 7 qt System Capacity
  • Diamond Shape Road Race Trap Door Baffle Assembly
  • Crank Scraper
  • Removable Windage/Anti-Slosh Baffle
  • 1/2" NPT Temperature Bung
  • Provision For Our Pan Mounted Dipstick
  • Magnetic Drain Plug
Baffled: Yes
Hardware Included: No
Sump Width: 13.5 inches
Sump Depth: 7.5 inches
Stoke: 4.5 inches
Recommended Accessory 5: 88-750 ? Big Block Ford 429-460 Four Piece Oil Pan Gasket
Recommended Accessory 4: 20-854 - Universal Steel Braided Dipstick Kit 1/4" N.P.T. Fitting
Recommended Accessory 3: 20-850 - Universal Dipstick Kit 1/4" N.P.T. Fitting
Recommended Accessory 2: 20-956 - Pickup Mounting Stud for 429-460 Based Engines
Recommended Accessory 1: 15-775 - Pickup
Pickup Included: No
Material: 16 Gauge Steel
Kicked Out: Yes
Gasket or Seal Included: No
Capacity: 7 Quart System Capacity
Finish: Silver Plating
Feature 7: Magnetic Drain Plug
Feature 6: Provision For Our Pan Mounted Dipstick
Feature 5: 1/2" NPT Temperature Bung
Feature 4: Removable Windage/Anti-Slosh Baffle
Feature 3: Crank Scraper
Feature 2: Diamond Shape Road Race Trap Door Baffle Assembly
Feature 1: 7 qt System Capacity
Drain Plug Included: Yes
Dipstick Port: Yes
Crank Scraper Included: Yes
Windage Tray Included: No
