Bilstein F4-BE5-G724-M0 - 9100 Bump Stop Series 46mm Monotube Bump Stop

Bilstein  |  SKU: BIL-F4-BE5-G724-M0
Sale price $35499 Regular price $39049

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Bilstein F4-BE5-G724-M0 - 9100 Bump Stop Series 46mm Monotube Bump Stop

M 9100 (Bump Stop)-Suspension Multi Purpose Bump Stop

46mm Monotube Bump Stop

Bilstein M 9100 (Bump Stop) is designed to provide a significant increase in compression control over the last few inches of suspension travel on custom off-road applications. M 9100 (Bump Stop) is available in 3 different stroke lengths ranging from 2-4 inch travel that can accommodate a wide range of custom mount configurations. M 9100 (Bump Stop) has a replaceable strike pad for easy maintenance. This bump stop utilizes a nitrogen fill valve which can be used to fully adjust the compression force. When properly applied, M 9100 (Bump Stop) will effectively decelerate the suspension and prevent harsh bottoming on custom off-road applications.

  • Filled with technology perfected over 3 decades of off-road dominance
  • Monotube gas pressure design maximizes heat dissipation
  • Available for lifted truck, custom truck, rock crawling and off-road racing applications
Finish: Nickel Plated
Lower Mount Type: Special
Mount Type: Special
Optional Reservoir Clamp: N/A
Extended Length (IN): 13.47
Segment: Motorsports
Collapsed Length (IN): 9.61
Spring Seat Included: No
Stroke/Travel Length (IN): 3.86
Body Design: Smooth Body (Non-Coilover)
Stroke/Travel Length (mm): 98.0
Extended Length (MM): 342.1
Rebound @0.52m/s: Custom
Internal Design: Monotube
Upper Mount Type: Special
Reservoir: No
Collapsed Length (MM): 244.1
Series: M 9100 (Bump Stop)
PartType: Bump Stop
Compression @0.52m/s: Custom
Piston Diameter: 46mm
Shaft Diameter: 1-1/4 in.
Shaft Diameter (mm): 31.8
