Bilstein 27-339022 - Shock Absorbers

Bilstein  |  SKU: BIL-27-339022
Sale price $1,17700 Regular price $1,29470

DISCLAIMER: This Item Is Special Ordered, which may have cancellation or return restrictions. Please see our terms and conditions for more information.


AVAILABILITY: This Item Is Out Of Stock.


PLEASE NOTE: Pictures may be representative of style, rather than the actual product. Read the description for more details.

Description

Bilstein 27-339022 - Shock Absorbers

AS3 Series - Suspension Shock Absorber

46mm Monotube Shock Absorber

Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up. Based on Bilstein’s race-proven 46mm monotube design, the AS3’s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup that’s common in conventional shock designs. The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately. The AS3 Series shock absorber offers consistent grip and optimal traction.

  • Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up.
  • Based on Bilstein’s race-proven 46mm monotube design, the AS3’s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup that’s common in conventional shock designs.
  • The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately.
Internal Design: Monotube
Piston Diameter: 46mm
Series: AS3 Series
Finish: Clear Anodized
Spring Seat Included: Yes
Adjustable Damping: Single Adjustable - Rebound
Collapsed Length (IN): 17.58
Stroke/Travel Length (IN): 5.45
Extended Length (IN): 22.83
Body Design: Threaded Body Screw Top (Coilover)
Piston Type: Sold Separately
Upper Mount Type: 1/2in Heim
PartType: Shocks / Struts
Stroke/Travel Length (mm): 138.4
Lower Mount Type: 1/2in Heim
Segment: Motorsports
Shaft Diameter: 14mm
Spring Hardware: E4-MSG-0096A00
Valving Identifier: Dry Kit (no valving)
Body Material: Aluminum
Collapsed Length (MM): 446.5
Extended Length (MM): 580.0
