Edelbrock 60859 - Single Perf SBC C-Bolt Head Comp

Edelbrock  |  MPN: 60859  |  SKU: EDEL-60859
$1,02850 $1,13135

PLEASE NOTE: Pictures may be repsentative of style, rather than the actual product. Read the description for more details.

Description

Edelbrock 60859 - Single Perf SBC C-Bolt Head Comp

Cylinder Head - Performer Centerbolt - Assembled - 2.020 / 1.600 in Valves - 165 cc Intake - 60 cc Chamber - 1.460 in Springs - Straight Plug - Aluminum - Small Block Chevy - Each

The Edelbrock #60859 Small-block Chevy cylinder head is designed for 1987-95 Throttle Body Injected (T.B.I.) and Tuned Port Injected (T.P.I.) 5.7L S/B Chevy engines originally equipped with center bolt valve covers. Performer center bolt cylinder head is 50-state street legal and accept factory center bolt valve covers. The intake bolt pattern utilizes the 1987-95, 73deg angle on the two center bolts. Will maintain stock compression ratio when used with the recommended head gasket. The Edelbrock Performer head is perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. They also feature the highest quality intake and exhaust valves and valve springs.

  • 50-State Street Legal Aluminum Cylinder Head
  • Out-of-the-Box Bolt-On Performance
  • Maintains Stock Compression Ratio
  • Accepts Stock Center Bolt Valve Covers
  • Accepts Edelbrock Aluminum Valve Covers
Exhaust Port Location: Standard
Family: Performer
Camshaft Type: Flat Tappet
Rotor Center Bore Inside Diameter: Straight
Exhaust Runner Volume: 65
Series: Performer
Quantity: Sold Individually
Horsepower: 250-425
Retainer Included: Yes
Valve Included: Yes
Intake Valve Diameter: 2.02
Valve Spring Diameter: 1.46
Valve Spring Maximum Lift: 0.575
Guide Plate Material: Hardened Steel
Construction Type: Complete
Combustion Chamber Volume: 60
Intake Runner Volume: 165
9040: D-215-94
CNC Ported: No
Material: Aluminum
Valve Stem Diameter: 0.3438
Rocker Arm Stud Diameter: 0.375
Guide Plates Included: Yes
RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Exhaust Valve Diameter: 1.60
EGR Port: Yes
Seat Material: Ductile Iron
Grade Type: Performance
Deck Thickness: 0.625
Head Casting Number: N/A
Guide Material: Manganese Bronze
Push Rod Diameter: (Suggested) 0.3125
Valve Angle: 23
Seat Angle: Exhaust 45 deg/Intake 45
Valve Springs Included: Yes
